Large Format Printers For Professionals


The JV100-160 is a new inkjet printer designed based on Mimaki’s “high image quality" and “reliability" technology, an expert in inkjet printers for sign graphics, with an emphasis on ease of use and high operability.JV100-160 discount

All the superior technologies mounted to the JV100-160, such as a new function of DAS that automatically makes adjustments when changing media, the new RasterLink7 RIP software that makes work faster and significantly reduces processing time, and the newly developed AS5 ink with high drying performance will back up your business.


  • • Improves reproducibility of special effects (such as transparency) of PDF data
  • • Increases RIP processing speed of PDF data by 25% on average
  • • Prints out the variable data by Variable print function
  • • Displays frequently used setting and pop-up windows
  • • PDF data with a lot of special effects embedded
  • • Variable print function
  • • Easy-to-check displays
  • Item


    Print head

    On-demand piezo head (staggered layout)

    Printing resolution

    360 dpi, 600 dpi, 720 dpi, 900 dpi, 1200 dpi



    Eco-solvent ink AS5/SS21 (C,M,Y,K,Lc,Lm,Or,Lk)


    600 ml / 2L ink pack

    Maximum drawing

    1,610 mm (63 in)


    Maximum width

    1,620 mm (64 in)


    1 mm or lower

    Roll diameter

    φ250 mm or less

    Roll weight

    45kg (99 lb) or less


    USB2.0 / Ethernet 1000BASE-T


    Single-phase (AC100-120V±10% / AC200-240V±10%) x2,
    (50/60Hz±1Hz) x2

    Power consumption

    AC100V:1.44 kw x2 or less/AC200V:1.92 kw x2 or less

    Operational environment

    Temperature: 20-30 degC (68-86 degF)  Humidity: 35-65Rh (without condensation)

    Dimensions (WxDxH)

    2,775 x 700 x 1,392 mm
    (109 x 28 x 55 in)

    Main unit weight

    166 kg (366 lb)
